Name: China Butt Fusion Reducer Fittings Manufacturers, Suppliers and Factory - Polyfusion
Brand: Polyfusion
SKU: 297307319

Butt Fusion Reducer fittings

We make these butt fusion fittings with pure virgin HDPE, no recycled blends, built only for gravity flow drainage and stormwater pipeline work.

Fusion isn't hard. Just trim the pipe and fitting ends dead flat, clean off any dirt or debris real quick, heat both surfaces evenly until they hit the right melt temp, press them together firm, and walk away.

This connection holds up to non-stop water flow and all kinds of outdoor weather, perfect for buried drainage jobs you don't want to dig back up to fix later.

Every fitting is a single solid piece, no thin welded seams or flimsy weak spots that break down first. The inner wall is finished smooth, no burrs or rough spots left over from production. The inner wall is smooth, no production burrs or rough spots to trap gunk and sediment from piling up, so you won't be dealing with clogged lines a few years down the road.

Product Advantages

Made with pure virgin HDPE, no recycled stuff mixed in. We don't use cheap fillers here, just solid raw material meant for gravity flow drainage and stormwater pipelines. These aren't general-use parts - built for buried outdoor jobs, meant to hold up long term without constant fixes.

Fusion is straightforward, no fancy skills needed. Trim pipe and fitting ends flat, wipe off dust or dirt fast. Heat both ends till they soften right, push together firm, leave alone to cool all the way. No extra tools, no glue, no gaskets, no extra parts to buy or haul to the site.

Once cooled, the joint is a permanent bond. No leaks, not even small seepage over time. No weak points at the connection, same strength as the pipe itself. Cuts down material costs and cuts installation time, no extra steps slowing down the job.

Solid one-piece construction, no welded seams that break easy. No thin, flimsy spots to wear out early. Inner wall is smooth, no burrs left from production. Doesn't trap dirt or gunk, so lines won't clog up years down the line.

Holds up to constant water flow and harsh outdoor weather. Works for buried lines you don't want to dig back up to repair. Available in SDR11 and SDR17 ratings to match standard HDPE pipes, priced simple for different project budgets.

Made on our German production lines, quick checks before shipping. Fits industrial, municipal and residential drainage work, no complicated specs to match - just reliable fittings for everyday pipeline jobs.

Polyfusion butt fusion fittings. Made with pure virgin HDPE only, no recycled material mixed in. Made for gravity flow drainage and stormwater pipelines, built for buried outdoor work that doesn't need constant repairs.

Product Specifications

ITEM	SIZE (dn-dn1)	Mark	L	H1	H2	SDR17	SDR13.6	SDR11
REDUCER	S75×50		160	80	60	√		√
	S75×63		160	80	63	√		√
	S90×40		175	79	60	√		√
	S90×50		175	79	60	√		√
	S90×63		175	79	65	√		√
	S90×75		175	79	70	√		√
	S110×40		185	89	60	√		√
	S110×50		185	89	60	√		√
	S110×63		185	89	63	√		√
	S110×75		185	89	70	√		√
	S110×90		185	89	79	√		√
	S125×50		195	87	60	√		√
	S125×63		195	87	63	√		√
	S125×75		195	87	70	√		√
	S125×90		195	87	80	√		√
	S125×110		195	87	82	√		√
	S140×63		180	80	67	√		√
	S140×75		180	80	75	√		√
	S140×90		180	80	83	√		√
	S140×110		180	80	83	√		√
	S140×125		180	80	85	√		√
	S160×63		215	98	63	√		√
	S160×75		215	98	70	√		√
	S160×90		215	98	80	√		√
	S160×110		215	98	82	√		√
	S160×125		215	98	87	√		√
	S160×140		215	98	90	√		√
	S180X63		200	80	63	√		√
	S180X75		200	80	70	√		√
	S180X90		200	80	79	√		√
	S180×110		200	80	100	√		√
	S180×125		200	80	100	√		√
	S180×140		200	80	100	√		√
	S180×160		200	80	80	√		√
	S200×63		230	112	63	√		√
	S200×75		230	112	70	√		√
	S200×90		230	112	79	√		√
	S200×110		230	112	82	√		√
	S200×125		230	112	87	√		√
	S200X140		230	112	92	√		√

ITEM	SIZE (dn-dn1)	Mark	L	H1	H2	SDR17	SDR13.6	SDR11
REDUCER	S200×160		230	112	98	√		√
	S200×180		230	112	105	√		√
	S225×90		218	85	80	√		√
	S225×110		218	85	80	√		√
	S225×125		218	85	80	√		√
	S225×160		218	85	80	√		√
	S225×180		218	85	80	√		√
	S225×200		218	85	80	√		√
	S250×90		230	90	100	√		√
	S250×110		260	90	100	√		√
	S250×125		230	90	89	√		√
	S250×160		230	90	93	√		√
	S250X180		230	90	95	√		√
	S250×200		230	90	97	√		√
	S250×225		230	90	100	√		√
	S280×110		255	105	95	√		√
	S280×160		245	105	105	√		√
	S280×200		245	105	120	√		√
	S280×225		245	105	120	√		√
	S280×250		245	105	130	√		√
	S315×110		235	90	87	√		√
	S315×160		235	90	87	√		√
	S315×180		240	90	90	√		√
	S315×200		240	90	90	√		√
	S315×225		240	90	105	√		√
	S315×250		240	90	100	√		√
	S315×280		240	90	110	√		√
	S355×110		270	105	110	√		√
	S355×160		275	105	110	√		√
	S355×200		260	105	110	√		√
	S355×250		240	105	110	√		√
	S355×280		235	105	110	√		√
	S355×315		230	105	110	√		√
	S400×110		270	100	110	√		√
	S400×160		270	100	110	√		√
	S400×200		270	100	110	√		√
	S400×250		250	100	110	√		√
	S400×315		230	100	110	√		√
	S400×355		230	100	110	√		√
	S450×110		270	105	110	√		√
	S450×160		270	105	110	√		√

ITEM	SIZE (dn-dn1)	Mark	L	H1	H2	SDR17	SDR13.6	SDR11
REDUCER	S450×200		270	105	110	√		√
	S450×225		270	105	110	√		√
	S450×250		270	105	110	√		√
	S450×280		255	105	110	√		√
	S450×315		250	105	110	√		√
	S450×355		245	105	110	√		√
	S450×400		245	105	110	√		√
	S500×160		280	100	110	√		√
	S500×200		280	100	110	√		√
	S500×250		280	100	110	√		√
	S500×315		275	100	110	√		√
	S500×355		275	100	110	√		√
	S500×400		275	100	110	√		√
	S500×450		275	100	110	√		√
	S560×315		280	105	110	√		√
	S560*355		265	105	110	√		√
	S560×400		260	105	120	√		√
	S560×450		250	105	120	√		√
	S560×500		240	105	120	√		√
	S630×250		285	110	100	√		√
	S630×315		285	110	100	√		√
	S630×355		285	110	110	√		√
	S630×400		285	110	120	√		√
	S630×450		275	110	120	√		√
	S630×500		260	110	120	√		√
	S630×560		250	110	130	√		√
	S710×400		370	120	110	√
	S710×500		350	120	110	√
	S710×630		280	120	110	√
	S800×400		420	120	100	√		√
	S800×500		390	120	110	√		√
	S800×630		330	120	120	√		√
	S800×710		300	120	125	√		√
	S900×800		310	120	125	√
	S1000×800		340	120	130	√
	S1000×900		310	125	137	√
	S1200×800		460	145	140	√
	S1200×1000		410	145	175	√

Raw Material

Qingdao Polyfusion Machinery Co., Ltd. holds that high-performance raw materials are the fundamental prerequisite for manufacturing top-tier HDPE piping systems. In the production of all our HDPE pipes and fittings, we have always adhered to the strict standard of selecting premium raw materials from well-known manufacturers around the world. These raw materials we adopt have been widely recognized as the high-grade base materials for HDPE pipe fitting production by professionals in the plastic piping industry.

The outstanding performance and ultra-stable physical and chemical properties of these raw materials are the core driving force for our products to maintain excellent quality. It is precisely relying on the superior quality of these raw materials that our HDPE pipes and fittings have firmly established a high-quality market position in the industry, and can consistently provide our cooperative partners with reliable and high-standard piping product solutions.

Packaging & Shipping

We adopt high-strength, shock-resistant, pressure-proof and wear-resistant packaging materials, and implement classified fixed packaging for different sizes and types of fittings to avoid collision, scratch and deformation during long-distance transportation and multiple handling. All packages are clearly marked with detailed product information, batch numbers, loading and unloading notes and shipping marks, which greatly facilitates your warehousing, sorting and subsequent construction use.

We regard professional packaging as an indispensable part of product quality assurance and international delivery service. For all our HDPE pipes and fittings, we have developed customized packaging solutions tailored to product specifications, shipping modes and regional transportation requirements, fully meeting international shipping standards for sea, land and air freight.

With rigorous packaging processes and strict quality control of each packaging link, we ensure that every batch of HDPE pipe fittings is delivered to customers around the world in a perfectly intact condition. Our packaging system not only effectively isolates all kinds of transportation risks, but also optimizes the packaging volume to improve loading efficiency and save your transportation costs to the greatest extent, creating more practical value for global cooperative partners.

Quality Assurance

Qingdao Polyfusion Machinery Co., Ltd. boasts a comprehensive portfolio of authoritative certifications and approvals including ISO9001, CE, WRAS, BV, SGS and CNAS, a solid testament to our stringent quality control system and professional manufacturing capabilities. We have forged our core competitive edges in the market with premium product quality, professional and efficient one-stop service, and highly competitive pricing. Taking maximizing customer benefits as our unwavering core goal, we regard product quality as the cornerstone of the company's sustainable development and lifeblood of our brand. After years of deep cultivation and steady development in the industry, we have built a stable and high-quality global partnership network, and our cooperative relations with partners worldwide have been continuously consolidated and deepened with excellent strength and reliable reputation.
